Descrizione
Riordinabile
Prodotto gestibile su richiesta in base alla disponibilità aggiornata del distributore.
Panoramica
Ubiquiti UniFi U7-Pro-XG-B è un access point Wi‑Fi 7 tri-band nero ad alte prestazioni, con uplink RJ45 10 GbE, supporto 6 GHz e gestione UniFi. Ideale per uffici, hospitality, retail e ambienti ad alta densità.
Specifiche tecniche
| Prodotto | Ubiquiti UniFi U7 Pro XG Black |
|---|---|
| MPN | U7-Pro-XG-B |
| Tipo prodotto | Access Point Wi‑Fi 7 indoor parete/soffitto |
| Standard Wi‑Fi | Wi‑Fi 7 / 802.11be |
| Radio | Tri-radio 2.4 GHz / 5 GHz / 6 GHz |
| Spatial streams | 6 |
| MIMO | 2.4 GHz 2×2, 5 GHz 2×2, 6 GHz 2×2 |
| Velocità 2.4 GHz | 688 Mbps |
| Velocità 5 GHz | 4.3 Gbps |
| Velocità 6 GHz | 5.8 Gbps |
| Uplink | 1 × RJ45 10 GbE |
| Supporto porta | 1/2.5/5/10 GbE |
| Copertura | 140 m² / 1.500 ft² |
| Client supportati | 300+ |
| Alimentazione | PoE+ |
| Consumo massimo | 22 W |
| Range tensione | 42.5–57 V DC |
| Montaggio | Soffitto / parete, Lite Mount incluso |
| Dimensioni | Ø 206 × 32,5 mm |
| Peso | 750 g |
| Materiale enclosure | Policarbonato stabilizzato UV, lega di alluminio |
| Funzioni | Wireless meshing, band steering, fast roaming 802.11r, 802.11k/v, PPSK, captive portal, VLAN dinamiche RADIUS |
| Gestione | UniFi Network 9.1.120 o successivo per versione Black |
| Certificazioni | CE, FCC, IC, Anatel |
| Temperatura operativa | -30 / 40 °C |
| Alimentatore incluso | No |
N.B.: Scheda informativa senza garanzia implicita o esplicita. Verificare compatibilità UniFi Network e PoE+.
Reorderable
Product manageable on request according to updated distributor availability.
Overview
Ubiquiti UniFi U7-Pro-XG-B is a high-performance black tri-band Wi‑Fi 7 access point with 10 GbE RJ45 uplink, 6 GHz support and UniFi management.
Technical specifications
| Product | Ubiquiti UniFi U7 Pro XG Black |
|---|---|
| MPN | U7-Pro-XG-B |
| Product type | Indoor Wi‑Fi 7 wall/ceiling access point |
| Wi‑Fi standard | Wi‑Fi 7 / 802.11be |
| Radio | Tri-radio 2.4 GHz / 5 GHz / 6 GHz |
| Spatial streams | 6 |
| MIMO | 2.4 GHz 2×2, 5 GHz 2×2, 6 GHz 2×2 |
| Max data rate 2.4 GHz | 688 Mbps |
| Max data rate 5 GHz | 4.3 Gbps |
| Max data rate 6 GHz | 5.8 Gbps |
| Uplink | 1 × RJ45 10 GbE |
| Port support | 1/2.5/5/10 GbE |
| Coverage | 140 m² / 1,500 ft² |
| Max client count | 300+ |
| Power method | PoE+ |
| Max power consumption | 22 W |
| Supported voltage range | 42.5–57 V DC |
| Mounting | Ceiling / wall, Lite Mount included |
| Dimensions | Ø 206 × 32.5 mm |
| Weight | 750 g |
| Management | UniFi Network 9.1.120 or later for Black version |
| Power adapter included | No |
Réapprovisionnable
Produit disponible sur demande selon la disponibilité actualisée du distributeur.
Aperçu
Ubiquiti UniFi U7-Pro-XG-B est un point d’accès Wi‑Fi 7 tri-bande noir avec uplink RJ45 10 GbE et gestion UniFi.
Spécifications techniques
| Produit | Ubiquiti UniFi U7 Pro XG Black |
|---|---|
| MPN | U7-Pro-XG-B |
| Type produit | Point d’accès Wi‑Fi 7 intérieur mur/plafond |
| Standard Wi‑Fi | Wi‑Fi 7 / 802.11be |
| Radio | Tri-radio 2.4 GHz / 5 GHz / 6 GHz |
| Flux spatiaux | 6 |
| Débit max 2.4 GHz | 688 Mbps |
| Débit max 5 GHz | 4.3 Gbps |
| Débit max 6 GHz | 5.8 Gbps |
| Uplink | 1 × RJ45 10 GbE |
| Couverture | 140 m² / 1 500 ft² |
| Clients max. | 300+ |
| Alimentation | PoE+ |
| Consommation max. | 22 W |
| Montage | Plafond / mur, Lite Mount inclus |
| Dimensions | Ø 206 × 32,5 mm |
| Poids | 750 g |
| Gestion | UniFi Network 9.1.120 ou ultérieur |
| Adaptateur secteur inclus | Non |
Reordenable
Producto gestionable bajo pedido según disponibilidad actualizada del distribuidor.
Resumen
Ubiquiti UniFi U7-Pro-XG-B es un punto de acceso Wi‑Fi 7 tri-banda negro con uplink RJ45 10 GbE y gestión UniFi.
Especificaciones técnicas
| Producto | Ubiquiti UniFi U7 Pro XG Black |
|---|---|
| MPN | U7-Pro-XG-B |
| Tipo producto | Punto de acceso Wi‑Fi 7 interior pared/techo |
| Estándar Wi‑Fi | Wi‑Fi 7 / 802.11be |
| Radio | Tri-radio 2.4 GHz / 5 GHz / 6 GHz |
| Flujos espaciales | 6 |
| Velocidad 2.4 GHz | 688 Mbps |
| Velocidad 5 GHz | 4.3 Gbps |
| Velocidad 6 GHz | 5.8 Gbps |
| Uplink | 1 × RJ45 10 GbE |
| Cobertura | 140 m² / 1.500 ft² |
| Clientes máx. | 300+ |
| Alimentación | PoE+ |
| Consumo máximo | 22 W |
| Montaje | Techo / pared, Lite Mount incluido |
| Dimensiones | Ø 206 × 32,5 mm |
| Peso | 750 g |
| Gestión | UniFi Network 9.1.120 o posterior |
| Adaptador incluido | No |
